A 580mm seat height is the lowest in the range, which lets shorter riders put both feet down and builds confidence on uneven trail ground. The 49cc single cylinder air cooled two stroke and chain final drive stay the same simple package used across the class.
The body measures 124x56x80cm over an 860mm wheelbase, with 240mm of ground clearance and a 2.2L tank for longer loops. Together with the low seat it makes a trail gasoline dirt bike that fits a wide span of rider heights.
ATVIMX is the brand of Wuyi Mole Motion Apparatus Co., LTD. in Zhejiang, China, exporting since 2016. Available through wholesale distribution for products for resale channels and ODM development.
You can click on the shopping cart to learn more about details, availability, and prices.
| ① Dimension | 124x56x80cm |
| ② Wheelbase | 860mm |
| ③ Seat height | 580mm |
| ④ Min ground clearance | 240mm |
| Engine | 49CC single-cylinder, air-cooled, 2 stroke |
| Tank volume | 2.2L |
| Frame material | Steel |
| Final drive | Chain |
| Transmission | Automatic |
| Wheel & tires | front: 2.5-10 rear: 2.5-10 |
| Max. speed | 40-45km/h |
| Max load capacity | 75kgs |
| Brake system | Front and rear disk |
| Suspension | Spring |
| Color available | Black/Red/Bule/Green/Orange |
| N.W./G.W. | 23kgs/27kgs |
| Carton size | 107x32x54cm |
| QTY | 148pcs/20FT, 352pcs/40HQ |
